UniFi Cloud Gateway Fiber
10G Cloud Gateway í borðtölvustærð með innbyggðu 4-porta 2.5 GbE rofa, valkvæmri NVR geymslu og fullum stuðningi við UniFi forrit.
- Inniheldur fullt UniFi forritasafn fyrir tækjastjórnun
- Stjórnar 50+ UniFi tækjum og 500+ biðlurum
- 5 Gbps beining með IDS/IPS
- (1) 10G SFP+ og (1) 10 GbE RJ45 WAN tengi
- (1) 10G SFP+ LAN tengi
- Innbyggður 4-porta rofi með (1) PoE+ porti
- NVMe SSD geymsluraufar*
- *NVMe SSD ekki innifalið. Uppsetning á SSD frá þriðja aðila krefst bakka fylgihlutar.
Þrívídd og myndbönd
Tækni
Tæknilegir eiginleikar
Upplýsingar úr ETIM gögnum framleiðanda. Vantar þig meira? Hafðu samband við tækniráðgjöf okkar.
| Dimensions | 212.8 x 127.6 x 30 mm (8.4 x 5 x 1.2") |
|---|---|
| UniFi Application Suite: Network | Yes |
| UniFi Application Suite: Protect | Yes |
| UniFi Application Suite: Access | Yes |
| UniFi Application Suite: Talk | Yes |
| UniFi Application Suite: Connect | Yes |
| Managed UniFi Devices | 50+ |
| Managed Cameras | (15) HD (8) 2K (5) 4K |
| Managed Access Hubs | 50 |
| Simultaneous Users Connected | 500+ |
| Max. WAN Port Count | 6 |
| Default WAN Ports | (1) 10G SFP+ (1) 10 GbE RJ45 |
| Port Layout: 2.5 GbE RJ45 | 4 (2.5G/1G/100M/10M) |
| Port Layout: 10 GbE RJ45 | 1 (10G/2.5G/1G) |
| Port Layout: 10G SFP+ | 2 (10G/1G) |
| IDS/IPS Throughput | 5 Gbps |
| Form Factor | Compact desktop |
| Stateful Firewall | Yes |
| Application-Aware Layer 7 Firewall | Yes |
| DPI & Traffic Identification | Yes |
| Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) | Yes |
| Content Filtering | Yes |
| Intrusion Prevention (IPS/IDS) | Yes |
| Ad Blocking | Yes |
| IDS/IPS Signatures | 55,000+ with CyberSecure |
| VLAN/Subnet-based Traffic Segmentation | Yes |
| License-Free SD-WAN | Yes |
| Site-to-Site VPN: Site Magic | Yes |
| Site-to-Site VPN: IPsec | Yes |
| Site-to-Site VPN: OpenVPN | Yes |
| VPN Server: Identity Endpoint One-Click VPN | Yes |
| VPN Server: Teleport Zero-Configuration VPN | Yes |
| VPN Server: WireGuard | Yes |
| VPN Server: OpenVPN | Yes |
| VPN Server: L2TP | Yes |
| VPN Client: OpenVPN | Yes |
| VPN Client: WireGuard | Yes |
| Multi-WAN Load Balancing | Yes |
| Dynamic Routing: OSPF | Yes |
| Dynamic Routing: BGP | Yes |
| Advanced QoS | Yes |
| Multicast DNS (mDNS) | Yes |
| Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) | Yes |
| Integrated RADIUS Server | Yes |
| RADIUS over TLS (RadSec) | Yes |
| Additional Internet Failover with UniFi LTE Backup | Yes |
| Internet Quality and Outage Reporting | Yes |
| MAC Address Table Size | 4,000 |
| Virtual Network Override | Yes |
| All Traffic Flows | Yes |
| NVR Storage | Selectable NVMe SSD up to 2 TB (No Storage option does not include NVMe SSD. Third-party SSD installation requires a tray accessory. 1/2 TB option includes tray accessory and NVMe SSD.) |
| PoE Budget | 30W |
| Voltage Range PoE Mode | 50-57V |
| Max. Power Consumption | 29.4W (Excluding PoE output) |
| Power Method | DC jack (54V DC/1.1A) |
| Power Supply | 54V DC/1.1A (Adapter included) |
| Supported Voltage Range | 100–240V AC |
| Heat Dissipation | 100 BTU/hr (Excluding PoE Output) |
| Processor | Quad-core ARM® Cortex®-A73 at 2.2 GHz |
| System Memory | 3 GB |
| Weight | Without SSD: 675 g (1.5 lb) With SSD: 734 g (1.6 lb) |
| Enclosure Material | Polycarbonate |
| LCM Display | 0.96" status display |
| Management | Ethernet Bluetooth |
| LEDs: Ethernet | Yes |
| LEDs: SFP+ | Yes |
| Button | (1) Factory reset |
| ESD/EMP Protection | Air: ± 8kV, contact: ± 4kV |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC, SRRC, Anatel: 04395-25-08356 |
