| Dimensions | 118.3 x 46.8 x 25.8 mm |
|---|
| Weight without mount | 130 g |
|---|
| Weight with flat wall mount | 178 g |
|---|
| Weight with 20° wedge mount | 200 g |
|---|
| Enclosure material | Polycarbonate |
|---|
| Flat wall mount material | aluminum alloy |
|---|
| 20° wedge mount material | polycarbonate |
|---|
| Weatherproofing | IPX4 |
|---|
| Sensor | 5MP CMOS sensor |
|---|
| Lens | Fixed focal length |
|---|
| Horizontal View Angle | 138 degrees |
|---|
| Vertical View Angle | 114 degrees |
|---|
| Diagonal View Angle | 155 degrees |
|---|
| Night mode | Built-in IR LED illumination and IR cut filter |
|---|
| Video Resolution | 2MP 1600 x 1200 |
|---|
| Max. Frame Rate | 30 FPS |
|---|
| Processor | Quad-core Arm® Cortex®-A53 based chip |
|---|
| Networking Interface | 802.11a/b/g/n/ac WiFi, Bluetooth™ 4.2 |
|---|
| Max. Power Consumption | 12 W |
|---|
| Power Requirements | 16—24 V AC, 1.25A max., 50/60 Hz |
|---|
| Supported Voltage Range | 16—24 V AC |
|---|
| LED | Link/activity |
|---|
| Buttons | (1) Ring button, (1) Factory reset |
|---|
| Mounting | Flat wall, 20° wedge (Included) |
|---|
| Ambient Operating Temperature | -10 to 40 °C |
|---|
| Ambient Operating Humidity | 0 to 90% noncondensing |
|---|
| Microphone | Yes (Can be disabled) |
|---|
| Speaker | Yes |
|---|
| Web Application | UniFi Protect |
|---|
| Mobile App | UniFi Protect iOS™ and Android™ |
|---|
| Transformer Input Rating (EU Version) | 230 V, 50/60Hz |
|---|
|
