UniFi Network Video Recorder G2
1U UniFi Protect NVR með innbyggðri AI atburðagreiningu, HDMI úttaki, fjórum 2.5”/3.5” HDD skúffum, og stuðningi fyrir allt að (30) 4K eða (60) Full HD myndavélar.
Þrívídd og myndbönd
Tækni
Tæknilegir eiginleikar
Upplýsingar úr ETIM gögnum framleiðanda. Vantar þig meira? Hafðu samband við tækniráðgjöf okkar.
| Dimensions | 442.4 x 43.7 x 325 mm (17.4 x 1.7 x 12.8") |
|---|---|
| Managed Cameras | With built-in HDMI Viewport disabled: (60) HD (50) 2K (30) 4K With built-in HDMI Viewport in use: (40) HD (30) 2K (20) 4K |
| Max. Simultaneous Viewport Streams | 16 4K cameras |
| Managed Access Hubs | 150+ |
| Storage Capacity | (4) 2.5/3.5" drive bays |
| Data Protection | Yes |
| Networking Interface | (1) 10G SFP+ port (1) 2.5 GbE RJ45 port (SFP+ port does not support 1G speeds.) |
| Power Redundancy | Yes (UniFi Power Backup Ready) |
| Form Factor | Rack Mount (1U) |
| Door Access Support | Yes |
| Management Application | UniFi Protect UniFi Access UniFi Connect |
| Hard Drive Capacity | (4) 2.5/3.5" HDD / SSD support |
| Max. Power Budget for Drives | 75W |
| Max. Power Consumption | 100W |
| Power Method | (1) Universal AC input, 100–240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC |
| Power Supply | AC/DC, Internal PSU, 100W |
| Processor | Qualcomm® Kryo™ CPU built on Arm® Cortex® technology (4 nm) (1) Prime core (3.2 GHz) (4) Performance cores (2.8 GHz) (3) Efficiency cores (2.0 GHz) |
| Memory | 8 GB |
| Management | Ethernet Bluetooth |
| Weight | 6 kg (13.2 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| LEDs: Ethernet | Yes |
| LEDs: SFP+ | Yes |
| LEDs: RPS | Yes |
| LEDs: HDD | Yes |
| LEDs: System | Yes |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC |
| Application Requirements: UniFi Protect | Version 7.1.55 or later. |
| Application Requirements: UniFi Access | Version 4.2.16 or later. |
Engin skjöl skráð á þessa vöru.
Leiðbeiningar
Leiðbeiningar og gögn
Gagnablöð, uppsetningarleiðbeiningar og fleiri gögn frá birgja.
