UniFi Optical Data Transport for Outdoor PoE Devices
- Áreiðanlegar Gigabit PoE lagnir yfir langar vegalengdir
- Áreiðanleg 24V/50V óvirk (passive) PoE flutningsleið
- Aukin ESD vörn og minni EMI truflanir
- Virkar áreiðanlega í miklum hita og kulda (-40 til 60° C)
Tækni
Tæknilegir eiginleikar
Upplýsingar úr ETIM gögnum framleiðanda. Vantar þig meira? Hafðu samband við tækniráðgjöf okkar.
| Dimensions | 196.4 x 93.5 x 32.4 mm ( 7.7 x 3.7 x 1.3") |
|---|---|
| Enclosure Material | Polycarbonat |
| Weight | 288 g (10.2 oz) |
| Weatherproofing | IPX5 |
| Surge Protection | Built-in high-current gas discharge tube for DC terminal block and PoE port |
| Networking Interface | (1) 1 Gbps SFP port (1) DC terminal block (1) DC RJ45 port DC injection (1) GbE PoE port (10/100 MbE not supported) |
| Input DC voltage | 16–57V |
| DC Output | Terminal block, 24V DC/50V DC, 2-wire |
| Power Method | DC Terminal Block, 2-Wire, 24V DC/50 VDC DC in RJ45 Port, 2-pair (4, 5+; 7, 8-) (24V DC input), or 4-pair (24V DC/50V DC input) passthrough PoE RJ45 port, 2-pair (4, 5+; 7, 8-) (24V DC input), or 4-pair (24V DC/50V DC input) PoE passthrough |
| Power Consumption | 1.5W (Typical) |
| ESD Protection | ± 24kV Contact / Air for Ethernet |
| Ambient Operating Temperature | -40 to 60° C (-40 to 140° F) (May be further restricted by the operating temperature range of the SFP module being used.) |
| Ambient Operating Humidity | 10 to 95% noncondensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC |
