Upplýsingar úr ETIM gögnum framleiðanda. Vantar þig meira? Hafðu samband við tækniráðgjöf okkar.
| Dimensions | 148 mm · 100 mm · 31 mm |
|---|---|
| Port Layout | 1 GbE RJ45 · 8 (4 PoE) (1G/100M/10M) |
| Max. PoE Output | Up to PoE |
| Total PoE Availability | 48 W |
| Form Factor | Compact desktop, wall |
| Switching Capacity | 16 Gbps |
| Total Non-Blocking Throughput | 8 Gbps |
| Forwarding Rate | 12 Mpps |
| Supported VLANs | 256 |
| MAC Address Table Size | 16,000 |
| Packet Buffer Size | 1.5 MB |
| Access Lists (IPv4) | 128 |
| Access Lists (MAC) | 128 |
| LACP Port Aggregation | ✓ |
| STP & RSTP | ✓ |
| Advanced IGMP Configuration (Querier, Fast Leave, Router Port) | ✓ |
| IGMP Snooping | ✓ |
| 802.1X Control | ✓ |
| MAC-Based ACLs & Device Isolation | ✓ |
| DHCP Snooping & Guarding | ✓ |
| Egress Rate Limit | ✓ |
| Flow Control | ✓ |
| Storm Control | ✓ |
| Multicast & Broadcast Rate Limiting | ✓ |
| MAC Address Blocking | ✓ |
| IP-Based ACLs & Network Isolation | ✓ |
| MAC-Based Port Restriction | ✓ |
| Port Isolation | ✓ |
| Port Mirroring | ✓ |
| Jumbo Frames | ✓ |
| LLDP-MED | ✓ |
| Voice VLAN | ✓ |
| Loop Protection | ✓ |
| Virtual Network Override | ✓ |
Tæknilýsingar og tenglar á síður framleiðanda. Allt á einum stað.
| PoE Ports |
|---|
| 4 PoE |
| Max. PoE Wattage per Port by PSE | 15.4 W |
|---|
| Max. Power Consumption | 12 W |
|---|
| Power Method | (1) AC/DC adapter (Included) |
|---|
| Power Input Method | AC input |
|---|
| Supported Voltage Range | 44–57 V DC/PoE |
|---|
| Weight | 432 g |
|---|
| Ambient Operating Temperature | -5 to 45 ° C |
|---|
| Ambient Operating Humidity | 5 to 95 % noncondensing |
|---|
