Upplýsingar úr ETIM gögnum framleiðanda. Vantar þig meira? Hafðu samband við tækniráðgjöf okkar.
| Dimensions | 86 mm · 46 mm · 33 mm |
|---|---|
| Weight | 100 g |
| Output Voltage | 48 V DC |
| Current Output | 0.32 A |
| Rated Voltage | 100–240 V AC |
| Rated Frequency | 50/60 Hz |
| Data In / PoE | RJ45 Shielded Socket |
| Input Current | 500 mA Max. |
| Inrush Current | <100 A peak at 25°C |
| Efficiency | 84.25 % |
| Switching Frequency | 65 kHz |
| Output Ripple | 200 mV pp |
| Line Regulation | ≤ 3 % |
| Load Regulation | ≤ 5 % |
| Max. Surge Discharge | 1500 A (8/20 μs) power |
| Peak Pulse Current | 36 A (10/1000 μs) data |
| Response Time | <1 ns |
| Shunt Capacitance | <5 pF data |
| Surge Protection | Difference and common mode |
| Ambient Storage Temperature | -30 to 70 ° C |
| Ambient Operating Temperature | 0 to 40 ° C |
| Ambient Operating Humidity | 10 to 95 % noncondensing |
