UniFi Switch Flex 2.5G
Sveigjanlegt 8-porta 2.5 GbE switch með 10 GbE RJ45/SFP+ samsettri tengiporti fyrir uplink sem hægt er að knýja með USB-C eða PoE+ millistykki.
- (8) 2.5 GbE tengi
- (1) 10 GbE PoE+ inntakstengi fyrir straum / samsett SFP+ tengi
- Valfrjáls straumur frá meðfylgjandi 5V, 3A USB-C straumbreyti
- Athugið. ESB útgáfan kemur eingöngu með evrópskri kló.
Þrívídd og myndbönd
Tækni
Tæknilegir eiginleikar
Upplýsingar úr ETIM gögnum framleiðanda. Vantar þig meira? Hafðu samband við tækniráðgjöf okkar.
| Dimensions | 212.9 x 76 x 33.5 mm (8.4 x 3 x 1.3") |
|---|---|
| Port Layout: 2.5 GbE RJ45 | 8 (2.5G/1G/100M/10M) |
| Port Layout: 10 GbE RJ45 | 1 (10G/5G/2.5G/1G/100M) (Combo port) |
| Port Layout: 10G SFP+ | 1 (10G/1G) (Combo port) |
| Form Factor | Compact Desktop, wall, DIN, magnetic (DIN and Magnetic are sold separately) |
| Switching Capacity | 60 Gbps |
| Total Non-Blocking Throughput | 30 Gbps |
| Forwarding Rate | 45 Mpps |
| Supported VLANs | 256 |
| MAC Address Table Size | 4,000 |
| STP & RSTP | Yes |
| Egress Rate Limit | Yes |
| Flow Control | Yes |
| Storm Control | Yes |
| Multicast & Broadcast Rate Limiting | Yes |
| Port Isolation | Yes |
| Port Mirroring | Yes |
| Jumbo Frames | Yes |
| Loop Protection | Yes |
| Max. Power Consumption | 14W with PoE input 14W with AC adapter input |
| Power Method | (1) USB Type-C, 5V DC, 3A (1) PoE+ |
| Power Input Method | USB Input PoE |
| Power Supply | AC/DC, external, 15W |
| Supported Voltage Range | 4.8—5.2V DC/USB 44V—57V PoE |
| Management | Ethernet |
| Weight | 395 g (0.87 lb) |
| Enclosure Material | Polycarbonate |
| Mount Material | Polycarbonate |
| Ambient Operating Temperature | -20 to 45° C (-4 to 113° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC, Anatel |
| Application Requirements: UniFi Network | Version 9.0.114 and later |
