UniFi Switch Flex XG
Fyrirferðalítil 5-porta Layer 2 switch sem styður 10 GbE hraða og hægt er að knýja með PoE eða 5V USB-C millistykki.
- (4) 10 GbE tengi
- (1) GbE PoE+ inntakstengi fyrir straum
Þrívídd og myndbönd
Tækni
Tæknilegir eiginleikar
Upplýsingar úr ETIM gögnum framleiðanda. Vantar þig meira? Hafðu samband við tækniráðgjöf okkar.
| Dimensions | 135 x 185 x 32 mm (5.3 x 7.3 x 1.3") |
|---|---|
| Port Layout: 1 GbE RJ45 | 1 (1G/100M/10M) |
| Port Layout: 10 GbE RJ45 | 4 |
| Form Factor | Compact desktop, wall |
| Switching Capacity | 82 Gbps |
| Total Non-Blocking Throughput | 41 Gbps |
| Forwarding Rate | 61 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 16,000 |
| Packet Buffer Size | 1.5 MB |
| Access Lists: IPv4 | 12 |
| Access Lists: MAC | 10 |
| LACP Port Aggregation | Yes |
| STP & RSTP | Yes |
| Advanced IGMP Configuration (Querier, Fast Leave, Router Port) | Yes |
| IGMP Snooping | Yes |
| 802.1X Control | Yes |
| MAC-Based ACLs & Device Isolation | Yes |
| DHCP Snooping & Guarding | Yes |
| Egress Rate Limit | Yes |
| Flow Control | Yes |
| Storm Control | Yes |
| Multicast & Broadcast Rate Limiting | Yes |
| MAC Address Blocking | Yes |
| IP-Based ACLs & Network Isolation | Yes |
| MAC-Based Port Restriction | Yes |
| Port Isolation | Yes |
| Port Mirroring | Yes |
| Jumbo Frames | Yes |
| LLDP-MED | Yes |
| Voice VLAN | Yes |
| Loop Protection | Yes |
| Virtual Network Override | Yes |
| Max. Power Consumption | 25W |
| Power Method | (1) PoE+ (1) USB Type-C, 5V DC, 5A |
| Power Input Method | USB Input PoE |
| Power Supply | AC/DC, external, 25W |
| Supported Voltage Range | 4.8—5.2V DC/USB 44V—57V PoE |
| Management | Ethernet |
| Heat Dissipation | 85.3 BTU/hr |
| Weight | 1.2 kg (2.7 lb) |
| Enclosure Material | Polycarbonate |
| ESD Protection | Air: ± 16kV, contact: ± 12kV |
| Ambient Operating Temperature | -5 to 45° C (23 to 113° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC, Anatel: 06606-25-08356 |
| Application Requirements: UniFi Network | Version 6.1.67 and later |
